IP69K Tri-proof LED Light
The IP69K is the highest level of this protection and is designed for applications where water jets are under high pressure and high temperature are used for specific wash-downs. This will also include special sensitization and chemical cleaning. In some instances, the cleaning process involves very intensive requirements for industries such as Food & Beverage as well as the vehicle industry.
Features
● IP69K, IP67
● PMMA IK08 / PC IK10
● Anti-ammonia
● Against water pressure of 100bar(1450psi) and temperature of 80°C
● System efficiency up to 130lm/W & 150lm/W option
● High CRI >80
● UGR<19 option
● Linkable options with quick connection
● Environmentally friendly, no mercury, No UV, No IR
● Wide beam angle 120°
● Energy Efficiency Grade: A+
● Quick Start instant 100% luminous flux
● Flicker Free driver
● 5 Year Warranty on complete fixture. (LED’s, Driver, & Housing)
● Certificate: CE,RoHs Certified
● Surface Mount or Suspended
| Model No. | TP2D-20W | TP4D-40W | TP5D-50W | TP5D-60W |
| Norminal Wattage | 20W | 40W | 50W | 60W |
| Dimension(mm) | D75*552 | D75*1152 | D75*1452 | D75*1452 |
| Weights | 1.1kg | 2.6KG | 3.0KG | 3.0KG |
| Input Voltage AC | AC200-240V 50/60Hz | |||
| LED Brand | SMD2835 sanan chip | |||
| Dimming Control | PWM, 0/1-10V ,Dali Optional | |||
| Operating Temperature | -40 to +60oC | |||
| Power Factor(PF) | >0.95 | |||
| UGR | <19 | |||
| Protection | OTP, OCP, OPV, SCP | |||
| Luminarie Efficiency(+/-5%) | 150lm/w | |||
| Beam Angle | 120° | |||
| CRI | Ra>80 | |||
| CCT | 4000K/5000K/6000K | |||
| Rating | IP69K,IP67,IK10 | |||
| Housing | PMMA/PC,Milky | |||
| Installation | Suspension, Surface mounting | |||
| Warranty | 5 Years | |||
| Lifetime | >50,000h | |||
| Certifications | CE, RoHS | |||
